Light-Duty Double Hole Pipe Clamp, Dual Plastic Rail Pipe Clamp, TTPG4 Series Pipe Clamp for Oil/Water Pipe Fixing

Product Overview

The TTPG4 series lightweight dual-hole guide rail pipe clamps are innovative pipeline fixing devices, specially designed for scenarios where two pipelines need to be laid side by side on guide rails. Integrating dual-pipeline fixing, snap-fit installation and quick locking functions, it can complete the installation and positioning of two cables, oil pipes or air pipes at one time. It is particularly suitable for occasions such as automated equipment and instruments that require compact and neat wiring.

Detailed Product Features and Advantages

1. Dual-Link Structure for Efficient Installation

• Synchronous Installation: Fixing of two pipelines can be completed with one operation, greatly improving installation efficiency.
• Uniform Spacing: Ensures two pipelines are laid in parallel with equal spacing, achieving neatness and uniformity.
• Space Saving: Two pipelines are integrated into one pipe clamp, saving more guide rail space than two single-pipe clamps.

2. Guide Rail Compatibility for Quick Assembly and Disassembly

• Snap-Fit Design: The bottom card slot matches the C-section steel guide rail, allowing manual installation by pressing with hands.
• Flexible Adjustment: Before locking, the pipe clamp can slide freely along the guide rail for easy positioning.
• Easy Maintenance: The entire pipe clamp can be easily removed after unlocking, facilitating the addition, reduction or replacement of pipelines.

3. Quick Locking for Reliable Fixing

• Linked Locking: One locking mechanism (lever or knob) can press two pipelines at the same time, ensuring simple operation.
• Anti-Loosening Design: The locking mechanism has a self-locking function to prevent loosening caused by vibration.

4. Nylon Material for Safe Protection

• Insulation and Scratch Resistance: Protects the pipeline surface and prevents wear.
• Corrosion Resistance: Suitable for general industrial environments.
• Vibration Damping and Noise Reduction: Effectively absorbs slight vibrations.

Core Parameters at a Glance

Typical Application Fields

• Automated Equipment: Side-by-side fixing of dual air pipes (intake/exhaust) or dual signal cables on robots and assembly lines.
• Machine Tool Equipment: Laying of dual cooling liquid pipes or dual lubricating oil pipes.
• Experimental Devices: Neat arrangement of dual sensor cables or dual fluid pipes.
• Medical Equipment: Fixing of dual liquid delivery pipes or dual gas pipes.

Selection Guide

Selection Steps:

1. Confirm the Guide Rail: Confirm the specification of the C-section steel guide rail to be used.

2. Confirm the Pipelines: Determine the respective outer diameters of the two pipelines to be fixed.

3. Select the Model: Select the corresponding TTPG4 specification according to the pipe diameter.

Notes:

• Ensure the sum of the outer diameters of the two pipelines is within the accommodation range of the pipe clamp.
• Mainly suitable for light-duty working conditions without severe vibration.

Our Advantages

• Efficient Design: Synchronous fixing of dual pipelines significantly improves installation efficiency.
• Convenient Operation: Snap-fit installation and quick locking save working hours.
• Reliable Quality: The nylon material has good toughness, and the locking mechanism operates smoothly.
